2026 Bad Boy 40 Series Tractor 4035HILB – #FBJ00856

Financing Price: $36,806 – 0% for 72 months (with approved credit)*

Cash Price: $33,460 or 0.99% for 84 months (with approved credit)*

*Price does not include $350 freight charge, $100 prep and fuel fee, or sales tax.



Bad Boy 4035 Tractor – Power, Comfort, and Control Redefined

Get More from Compact

The 4035 Series is the largest tractor in the Bad Boy Tractor stable with 35hp. The eco-friendly “A” Series diesel engine sips fuel while providing maximum performance in speed, power and lifting up to 2,200 lbs.

Hydro Max Transmission

Say goodbye to pre-set engine throttle positions. The 4035 Series engine RPM automatically increases or decreases as you move the foot pedals. Hydro Max is quiet, smooth, easy and eco-smart.

Work in Any Weather

The 4035 Series is available with or without a fully climate-controlled, all-weather cab. So bring on the rain, snow or blistering heat because nothing can stop you from working with an attitude.



4035 Engine

Engine: 3 Cylinder, Water-Cooled, Diesel

Engine HP @ RPM: 35

Displacement (in.): 104.5

Number Of Cylinders: 3

Fuel Tank (gal.): 7.1



4035 Drivetrain

Transmission: HST

Number Of Speeds: 3 Range

Clutch: No

Brakes: Wet, Multi-Disc



4035 Hydraulics

Type: Hydro-Static Power Steering

Total Hydraulic Flow (Power Steering + Implement): 12.6 (4.4+8.2)

3-Point Hitch: Cat 1

Rear Remote Valve: Optional (Up To 2)

3-Point Hitch Lift Capacity @ 24″ Behind Lift Point (lbs.): 2,425



4035 Dimensions

Overall Length: 134.88″

Overall Width: 4035H – 56.7″ | 4035CH – 55.6″

Overall Height: 4035H – 97″ | 4035CH – 86″

Wheelbase: 65.7″

Minimum Ground Clearance: 13.1″

Weight: 4035H – 3,164 lbs. | 4035CH – 3,551 lbs.



4035 PTO

Type: Independent

Rear (Mid) PTO Speed: 540

PTO HP: 29.5



4035 Electrical

Battery: 12 V, 540 CCA

Alternator: 12 V, 50 A



4035 Wheels & Tires

IND (Front): 28X8.50-15

IND (Rear): 43X16.00-20



4035 Loader – Model BBL400

Standard Bucket Size (in.): 62

Maximum Lift Height (in.): 104

Dig Depth (in.): 1.8

Lift Capacity To Full Height At Pivot Pin (lbs.): 2,200

Breakout Force (lbs.): 3,660

Shipping Weight (lbs.): 1,007



4035 Backhoe – Model BBH400

Standard Bucket Size (in.): 16

Type: Subframe-Mounted, Quick Attach

Maximum Dig Depth (in.): 92.2

Dig Force Bucket (lbs.): 4,380

Shipping Weight (lbs.): 1,270
